Tuya WiFi GSM Home Burglar Security Alarm System

Description

Tuya Smart WiFi & GSM Alarm System for home and office security, easy to DIY.

Specifications
Hub (1pc)
Power Supply: Micro USB 110/220VAC to 5V, 1000mA
Backup Battery: 3.7V, 500mAh Rechargeable Lithium Battery
Consumption: <55mA@normal
Siren Output: <500mA
Radio Frequency: 433Mhz
Support 4G network(850/900/1800/1900MHz)-G300PLUS
Support 2G GSM-G300
Wi-Fi: IEEE802.11b/g/n
Operation Temperature: -10~55℃

Remote Controller (2pcs)
Power Supply: DC 3V (CR2025 Lithium Battery x1)
Standby Current: <5uA
Alarm Current: <15mA
Transmitting Distance: <80m (Open Area and No Interference)
Radio Frequency: 433Mhz
Operation Temperature: -10~55℃

Door/Window Sensor (1pc)
Power Supply: DC 3V (CR2032 Lithium Battery x1)
Standby Current: <8uA
Alarm Current: <15mA
Transmitting Distance: <80m (Open Area/No Interference)
Radio Frequency: 433Mhz
Operation Temperature: -10~55℃

PIR Motion Sensor (1pc)
Power Supply: 1.5V AA Battery x3
Standby Current: <15uA
Alarm Current: <25mA
Detection Scope: <12m/110°
Transmitting Distance: <80m (Open Area and No Interference)
Radio Frequency: 433Mhz
Operation Temperature: -10~55℃

RFID Tag (2pcs)
Chip: 4100/4200
Frequency: 125KHz
Read Distance: <2cm

Wired Siren (1pc)
Power Supply: Micro USB 110/220VAC to 5V, 1000mA
Backup Battery: 3.7V, 300mAh Rechargeable Lithium Battery
Standby Current: <15mA
Alarm Current: <230mA
Volume: 100dB
Radio Frequency: 433Mhz
Operation Temperature: -10~55
